Data Visualization

Annual area of drought impact on vegetation productivity (2000-2019)

Data Visualization Created 14 Dec 2021 Published 15 Dec 2021 Last modified 10 Jan 2022
1 min read

More information

Unit
The intensity values (anomalies) are standardised and hence are expressed in standard devitation units. The affected area is expressed in km2.

Methodology
Standardized anomalies of yearly vegetation productivity during 2000-2019 are analysed in areas with drought pressure due to low soil moisture content. Anomalies are expressed in standard deviations compared to the long term average vegetation productivity conditions for each 500m grid cell in the EEA-39 region. The size of the impacted area is calculated from the sum of those grid cells where both the soil moisture and the vegetation productivity anomaly was below -1 standard deviation in the given year. The vegetation index used in the indicator is the Plant Phenology Index (PPI, Jin and Eklundh, 2014). PPI is based on the MODIS Nadir BRDF-Adjusted Reflectance product (MODIS MCD43 NBAR. The product provides reflectance data for the MODIS “land” bands (1-7) adjusted using a bi-directional reflectance distribution function. This function models values as if they were collected from a nadir-view to remove so called cross-track illumination effects. The product is distributed with 500 m pixel size (MODIS Sinusoidal Grid) with 8-days compositing period. The web map service was derived from a 16 bit time series.

Reference: Jin, H., Eklundh, L. (2014): A physically based vegetation index for improved monitoring of plant phenology, Remote Sensing, 152, 512–525. Inpout to the PPI index was from MODIS NDVI.

Data sources

Vegetation productivity 2000-2016 provided by European Environment Agency (EEA)

Download data

HTML CSV TSV

JSON Exhibit JSON XML XML with Schema

Related content

Based on data

Data Vegetation productivity 2000-2016 The raster files are the above ground vegetation productivity time-series and the derived linear trend for the period 2000-2016.The data set addresses trends in land surface productivity derived from remote sensing observed time series of vegetation indices. The vegetation index used in the indicator is the Plant Phenology Index (PPI, Jin and Eklundh, 2014). PPI is based on the MODIS Nadir BRDF-Adjusted Reflectance product (MODIS MCD43 NBAR. The product provides reflectance data for the MODIS “land” bands (1 - 7) adjusted using a bi-directional reflectance distribution function. This function models values as if they were collected from a nadir-view to remove so called cross-track illumination effects. The Plant Phenology Index (PPI) is a new vegetation index optimized for efficient monitoring of vegetation phenology. It is derived from radiative transfer solution using reflectance in visible-red (RED) and near-infrared (NIR) spectral domains. PPI is defined to have a linear relationship to the canopy green leaf area index (LAI) and its temporal pattern is strongly similar to the temporal pattern of gross primary productivity (GPP) estimated by flux towers at ground reference stations. PPI is less affected by presence of snow compared to commonly used vegetation indices such as Normalized Difference Vegetation Index (NDVI) or Enhanced Vegetation Index (EVI).The product is distributed with 500 m pixel size (MODIS Sinusoidal Grid) with 8-days compositing period.
